Agco

ST34a

Tractor

Operating Weight
2,844 lb
Displacement
92 in³
Power Measured @
2,600 rpm
Gross Power
33.0 hp
All tractors
Agco ST34a Tractor
1 / 5
Image 1 of 5
Image: tractordata.com

Specifications

19 data points

Operating Specifications

Operating Specifications specifications
Operating Weight2,844 lb
3 Point Hitch Lift Capacity @ 24 inches2,535 lb
3 Point Hitch TypeCat I
Turning Radius100 in

Engine

Engine specifications
Displacement92 in³
Power Measured @2,600 rpm
Gross Power33.0 hp
Number of Cylinders3
Aspirationnatural
PTO Power25.9 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity9.1 gal/min

Dimensions

Dimensions specifications
Ground Clearance14 in
Height - Top of Cab81 in
Wheelbase71 in
Overall Length10 in
Tire SizeAg R1
Width Outside Frame62 in

Transmission

Transmission specifications
Transmission Type8x8 synchroshuttle

Axles

Axles specifications
Final Driveoutboard spur gear
