Agrale
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 3,968 lb |
|---|---|
| Fuel Capacity | 10.4 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 1,433 lb |
| Turning Radius | 108 in |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 14 V |
| Tire Size Front - 2wd / 4wd | 7.5L/15R1 |
| Hydraulic System Fluid Capacity | 4.5 gal |
| Engine Oil Capacity | 1.6 gal |
Engine
| Engine Model | M 790 |
|---|---|
| Displacement | 78 in³ |
| Power Measured @ | 3,000 rpm |
| Gross Power | 30.0 hp |
| Number of Cylinders | 2 |
| Torque Measured @ | 2,550 rpm |
| Max Torque | 51 lb-ft |
| PTO Power | 22.2 hp |
Hydraulic System
| Pump Flow Capacity | 8.0 gal/min |
|---|---|
| Number of Remote Control Valves | 6 |
| Relief Valve Setting | 2,611 psi |
Dimensions
| Wheelbase | 56 in |
|---|---|
| Overall Length | 10 in |
| Overall Width | 54 in |
| Height | 53 in |
Transmission
| Max Speed | 14.1 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 2 |
Tires & Wheels
| Rear Tires Size | 9.5/24R1 |
|---|
