Specifications
27 data points
Engine
| Power | 74.3 hp |
|---|---|
| Torque | — |
| Emissions | Stage IIIB - EPA Tier 4F |
| No. of cylinders | 4 |
| Brand | Deutz |
| Noise Level | 103 dB(A) |
Hydraulic System
| Hydraulic circuit | 13.5 gal/min |
|---|---|
| Main Pump | 23 cc gear pumps |
| Working Pressure | 2,466 psi |
Brakes & Steering
| Service | Hydraulic sealed multi-disc |
|---|---|
| Parking | Mechanical sealed multi-disc |
General Specifications
| Transmission | Torque converter |
|---|---|
| Empty weight | 11,001 lb |
| Load Capacity | 22,046 lb |
| Chassis | Articulated |
| Heaped Hopper Capacity | 4,789.5 gal |
| Level Hopper Capacity | 3,139.7 gal |
| Reversability | Non-reversible |
| Unloading System | Rotating |
| Water Hopper Capacity | 1,949.8 gal |
Driving
| Max Speed | 19.9 mph |
|---|---|
| External turning radius | 232 in |
| Tires | 500/60-225 |
| Traction | 4x4 |
| Max Gradient | 60.0 % |
Deposit Capacity
| Fuel | 70.0 gal |
|---|---|
| Hydraulic System | 65.0 gal |
