Bobcat
Caterpillar
305.5E CR
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 11,660 lb |
|---|---|
| Fuel Capacity | 22.1 gal |
| Hydraulic Pump Flow Capacity | 46.9 gal/min |
Engine
| Engine Model | V2003-M-DI-TE2B |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 47.9 hp |
Dimensions
| Height - Top of Cab | 100 in |
|---|---|
| Tail Swing Radius | 64 in |
| Width to Outside of Tracks | 76 in |
| Removal Counterweight Clearance | 26 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 60 in |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 16 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 157 in |
|---|---|
| Max Reach Along Ground | 241 in |
| Max Vertical Wall Digging Depth | 121 in |
| Max Loading Height | 163 in |
| Shipping Length of Unit | 222 in |
| Max Cutting Height | 229 in |
| Shipping Height of Unit | 100 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
