Branson
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 4,087 lb |
|---|---|
| Fuel Capacity | 11.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,580 lb |
| 3 Point Hitch Type | Cati I |
Engine
| Displacement | 127 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 42.0 hp |
| Number of Cylinders | 4 |
| Aspiration | naturally aspirated |
Hydraulic System
| Pump Flow Capacity | 8.4 gal/min |
|---|
Dimensions
| Height - Top of Cab | 97 in |
|---|---|
| Wheelbase | 70 in |
| Overall Length | 12 in |
| Tire Size | front: 8-18 rear 12.4-28 |
| Width Outside Frame | 72 in |
Transmission
| Number of Forward Gears | 12 |
|---|---|
| Transmission Type | synchronized |
| Number of Reverse Gears | 12 |
