Branson
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 4,116 lb |
|---|---|
| Fuel Capacity | 9.8 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,580 lb |
| 3 Point Hitch Type | Cat I |
| Operating Voltage | 12 V |
Engine
| Engine Model | A2300N2 |
|---|---|
| Displacement | 140 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 47.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 37.8 hp |
Hydraulic System
| Pump Flow Capacity | 8.4 gal/min |
|---|
Dimensions
| Height - Top of Cab | 97 in |
|---|---|
| Wheelbase | 72 in |
| Overall Length | 10 in |
| Tire Size | front: 8-18 rear:12.4-28 |
| Width Outside Frame | 72 in |
Transmission
| Number of Forward Gears | 12 |
|---|---|
| Transmission Type | synchronized |
| Number of Reverse Gears | 12 |
