Case IH

JX70

Tractor

Displacement
177 in³
Power Measured @
2,500 rpm
Gross Power
62.0 hp
All tractors
Case IH JX70 Tractor
1 / 5
Image 1 of 5
Image: tractors.fandom.com

Specifications

17 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity23.8 gal
3 Point Hitch Lift Capacity @ 24 inches4,010 lb
Alternator Supplied Amperage85 A

Engine

Engine specifications
Displacement177 in³
Power Measured @2,500 rpm
Gross Power62.0 hp
Number of Cylinders3
AspirationTurbocharged
PTO Power52.0 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity21.7 gal/min
Relief Valve Setting2,755 psi

Dimensions

Dimensions specifications
Height - Top of ROPS/FOPS97 in

Transmission

Transmission specifications
Number of Forward Gears12
Number of Reverse Gears12

Tires & Wheels

Tires & Wheels specifications
Rear Tires Size14.9 x 28

Production

Production specifications
SeriesJX Series
Years Manufactured2,007 – 2,008
