Case IH
Landini
Trekker 75 F
Tractor
20 specifications
Case IH
PUMA 165
- Operating Weight
- 13,900 lb
- Displacement
- 409 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 165.0 hp
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 13,900 lb |
|---|---|
| Fuel Capacity | 71.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 8,049 lb |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 19.5 gal |
| Engine Oil Capacity | 16.0 gal |
| DEF tank capacity | 12.7 gal |
Engine
| Displacement | 409 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 165.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Cross-flow aspiration/turbocharged |
| PTO Power | 140.0 hp |
Hydraulic System
| Pump Flow Capacity | 29.8 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
| Pump Type | Closed center Pressure Flow Compensating |
Dimensions
| Wheelbase | 108 in |
|---|
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 18 |
| Number of Reverse Gears | 6 |
Production
| Series | Puma Series |
|---|---|
| Years Manufactured | 2,007 – 2,010 |
Comparable machines
Other tractors in a similar weight class.
