Case IH

RB444

Baler

Bale Width
47 in
Overall Width
60 in
Overall Width
85 in
Overall Height
85 in
All balers
Case IH RB444 Baler
1 / 5
Image 1 of 5
Image: tractorhouse.com

Specifications

45 data points

Engine

Engine specifications
Number of hydraulic remote circuits1
Tractor power34.9 hp

Dimensions

Dimensions specifications
Overall Length135 in
Overall Width85 in
Overall Height85 in
Weight304 lb
Tractor PTO Power Required34.9 hp

Tires & Wheels

Tires & Wheels specifications
Standard11L x 14 6 ply

Bale Size

Bale Size specifications
Bale Width47 in
Bale Diameter - max49 in
Bale Diameter - min30 in
Bale Weight - max750 lb
Bale Weight - min300 lb

Baler Pickup

Baler Pickup specifications
Overall Width60 in
Number of Bars4
Tine to Tine Width44 in
Number of Tines72
Lift Typesingle-cam track
Tine spacing3 in
Pickup gauge wheel1standard
Pickup liftManual
Windguard description9 rods adjustable
Outer tine-to-tine width, standard45 in
Pickup working width60 in
Number of Tine Rows4

Wrapping System

Wrapping System specifications
Twine Ball Capacity4
Twine TypeElectric manual
Netwrap, meshwrap featureNo option

Bale Chamber

Bale Chamber specifications
Number of Belts6
Belt Width7 in
Bale chamberVariable chamber
Bale ejectorBale ramp spring-loaded
Belt description3-ply laced chevron
Forming mechanism_Belts6
Forming mechanism_Rolls5
Tensioning method2 extension spring assemblies

Years of Manufacture

Years of Manufacture specifications
First Entry Date9/27/2007
Manufacturing StatusCurrent
Revision Date1/27/2012 - 4/30/2017

Power Take-Off (PTO)

Power Take-Off (PTO) specifications
PTO speed540 rpm
DriveShearbolt

Sales Literature

Sales Literature specifications
Document Date7/1/2015
Document NumberHF-5148-15
Literature Date42,430
Literature NumberCIH03281601
