Case IH
Hesston
946 Auto-Cycle
Baler
20 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Engine
| Number of hydraulic remote circuits | 1 to 4 |
|---|---|
| Tractor power | 60.0 – 105.0 hp |
Dimensions
| Overall Length | 175 in |
|---|---|
| Overall baler width-Min | 99 in |
Tires & Wheels
| Standard | 18L-16.1SL 10PR |
|---|---|
| Option | 31x13.5-15 8 ply |
Bale Size
| Bale Width | 7 in |
|---|---|
| Bale Diameter - max | 60 in |
| Bale Diameter - min | 36 in |
| Bale Weight - max | 1,799 lb |
| Bale Weight - min | 399 lb |
Baler Pickup
| Number of Bars | 4 |
|---|---|
| Number of Tines | — |
| Tine spacing | 3 in |
| Pickup gauge wheel | One standard two available |
| Pickup lift | Manual or hydraulic |
| Outer tine-to-tine width, standard | 71 in |
| Pickup working width | 80 in |
| Optional pickup working width | 90 in |
| Outer tine-to-tine width, optional | 82 in |
Wrapping System
| Twine Ball Capacity | — |
|---|---|
| Twine Type | Automatic electric |
| Netwrap, meshwrap feature | Netwrap available |
Bale Chamber
| Belt Width | 7 in |
|---|---|
| Bale chamber | Variable chamber |
| Bale ejector | Bale ramp spring-loadedhydraulic opt. |
| Belt description | Premium Laced std Endless opt. |
| Forming mechanism_Belts | 6 |
| Forming mechanism_Rolls | 6 |
| Tensioning method | Single hyd. Cylinder In-Cab control opt. |
Years of Manufacture
| First Entry Date | 8/27/2013 |
|---|---|
| Manufacturing Status | Current |
| Revision Date | 9/29/2013- 4/30/2017 |
Power Take-Off (PTO)
| PTO speed | 1,000 rpm |
|---|---|
| Drive | Multiplate ship clutch |
Sales Literature
| Document Date | 7/1/2015 |
|---|---|
| Document Number | HF-5148-15 |
| Literature Date | 42,430 |
| Literature Number | CIH03281601 |
