Case IH

WDX2302

Mower Conditioner

Operating Weight w/o Attachment
12,302 lb
Max Speed
16.5 mph
Displacement
456 in³
Power
225.0 hp
All mower conditioners/windrowers
Case IH WDX2302 Mower Conditioner
1 / 5
Image 1 of 5
Image: tractorhouse.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight w/o Attachment12,302 lb
Fuel Capacity120.0 gal
Front Tire Size23.1 x 26 10PR turf
Rear Tire Size14Lx16.1 8PR
Alternator Supplied Amperage135 A
Operating Voltage24 V

Engine

Engine specifications
Displacement456 in³
Power225.0 hp
AspirationTurbocharged air-to-air intercooler
Power Measured @2,100 rpm
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance40 in
Height - Top of Cab135 in
Wheelbase138 in
Front Wheel Tread Width130 in
Rear Wheel tread Width - max120 in
Rear Wheel Tread Width - min90 in
Length w/ Header267 in
Length w/o Header199 in

Transmission

Transmission specifications
Max Speed16.5 mph
Final Drive TypePlanetary hubs
Transmission TypeDual speed hydrostatic
