Case
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Fuel Capacity | 52.0 gal |
|---|---|
| Cooling System Fluid Capacity | 13.1 gal |
| Final Drives Fluid Capacity | 2.1 gal |
| Engine Oil Capacity | 3.8 gal |
| Hydraulic Fluid Capacity | 147.1 gal |
Engine
| Displacement | 451 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 125.0 hp |
| Net Power | 105.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 359 lb-ft |
Hydraulic System
| Pump Flow Capacity | 52.1 gal/min |
|---|---|
| Relief Valve Pressure | 2,200 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 114 in |
| Width Over Tracks | 78 in |
Transmission
| Max Speed - Forward | 6.0 mph |
|---|---|
| Max Speed - Reverse | 7.2 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
