Case
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 56.1 gal |
|---|---|
| Cooling System Fluid Capacity | 6.5 gal |
| Final Drives Fluid Capacity | 2.1 gal |
| Engine Oil Capacity | 4.0 gal |
| Hydraulic Fluid Capacity | 17.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | 6T-590 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 124.0 hp |
| Net Power | 119.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 372 lb-ft |
Hydraulic System
| Pump Flow Capacity | 33.3 gal/min |
|---|---|
| Relief Valve Pressure | 2,500 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 97 in |
| Width Over Tracks | 110 in |
Transmission
| Max Speed - Forward | 5.8 mph |
|---|---|
| Max Speed - Reverse | 6.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 62 in |
| Number of Track Rollers per Side | 7 |
| Number of Shoes per Side | 43 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 508 in |
| Ground Contact Area | 3,868 in³ |
