Case
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 8,830 lb |
|---|---|
| Max Speed | 12.3 mph |
| Fuel Capacity | 20.7 gal |
| Cooling System Fluid Capacity | 4.5 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 A |
| Hydraulic System Fluid Capacity | 17.0 gal |
| Tire Size | 12.00 x 16.5 |
| Chain Box Fluid Capacity - each side | 2.0 gal |
| Engine Oil Fluid Capacity | 3.2 gal |
Engine
| Engine Model | Family III 445T/M2 Tier II certified |
|---|---|
| Displacement | 274 in³ |
| Power Measured @ | 2,300 rpm |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 22.1 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Gear pump |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 80 in |
| Wheelbase | 47 in |
| Width Over Tires | 65 in |
| Reach at Max Lift and Dump | 27 in |
| Length with Bucket | 142 in |
| Clearance at Max Lift and Dump | 95 in |
| Turning Radius from Center - inc bucket | 84 in |
| Turning Radius from Center - machine rear | 62 in |
| Length w/o Bucket | 109 in |
Loader
| Bucket Capacity | 0.71 yd³ |
|---|---|
| Breakout Force | 6,200 psi |
| Operating Load Rating | 2,450 lb |
| Tipping Angle | 4,900 ° |
