Case
Furukawa
FD40-1
Crawler Dozer
21 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 14,432 lb |
|---|---|
| Fuel Capacity | 27.6 gal |
| Cooling System Fluid Capacity | 4.2 gal |
| Final Drives Fluid Capacity | 1.6 gal |
| Engine Oil Capacity | 2.8 gal |
| Hydraulic Fluid Capacity | 8.6 gal |
Engine
| Engine Model | 4-390 |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 71.0 hp |
| Net Power | 63.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 186 lb-ft |
Hydraulic System
| Pump Flow Capacity | 22.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,500 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 101 in |
| Length of Track on Ground | 158 in |
| Width Over Tracks | 66 in |
Transmission
| Max Speed - Forward | 6.3 mph |
|---|---|
| Max Speed - Reverse | 6.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Undercarriage
| Track Gauge | 53 in |
|---|---|
| Number of Track Rollers per Side | 5 |
| Number of Shoes per Side | 36 |
| Number of Carrier Rollers per Side | 1 |
| Standard Shoe Size | 14 in |
