Case
621B XT
- Operating Weight
- 58,178 lb
- Bucket Capacity - heaped
- 3.00 yd³
- Gross Power
- 138.0 hp
- Net Power
- 126.0 hp
.jpg)
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 58,178 lb |
|---|---|
| Fuel Capacity | 51.0 gal |
| Engine Oil Fluid Capacity | 3.8 gal |
| Front Axle/Diff Fluid Capacity | 5.5 gal |
| Rear Axle/Diff Fluid Capacity | 5.5 gal |
| Cooling System Fluid Capacity | 7.0 gal |
| Transmission Fluid Capacity | 5.0 gal |
Engine
| Engine Model | 6T 590 |
|---|---|
| Displacement | 4 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 138.0 hp |
| Net Power | 126.0 hp |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 443 lb-ft |
| Bore | 4 in |
| Stroke | 5 in |
Hydraulic System
| Raise Time | 5.7 s |
|---|---|
| Lower Time | 5.0 s |
| Dump Time | 1.7 s |
Dimensions
| Height - Top of Cab | 130 in |
|---|---|
| Wheelbase | 114 in |
| Width Over Tires | 96 in |
| Hinge Pin - Max Height | 154 in |
Transmission
| Max Speed - Forward | 20.6 mph |
|---|---|
| Max Speed - Reverse | 15.0 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.00 yd³ |
|---|---|
| Bucket Capacity - struck | 2.60 yd³ |
| Dump Clearance at Max Raise | 119 in |
| Bucket Width | 103 in |
