CaterpillarBoxer
427
Compact Track Loader
19 specifications
1 / 5
Image 1 of 5
Specifications
61 data points
Operating Specifications
| Breakout Force - Tilt Cylinder | 7,285 lb |
|---|---|
| Tipping Load | 6,580 lb |
| Rated Operating Capacities - 35% Tipping Load | 2,303 lb |
| Rated Operating Capacities - 50% Tipping Load | 3,290 lb |
| Ground Contact Area | 2,561 in³ |
| Ground Pressure | 4 psi |
| Rated Operating Capacity with Optional Counterweight | 3,540 lb |
Engine
| Engine Model | Cat C3.3B DIT (turbo) |
|---|---|
| Displacement | 203 in³ |
| Net Power | 72.9 hp |
| Bore | 4 in |
| Stroke | 5 in |
| Gross Power - SAE J1995 | 74.3 hp |
| Net Power - ISO 9249 | 73.7 hp |
| Net Power - SAE 1349 | 72.9 hp |
| Peak Torque - 1,500 rpm - SAE J1995 | 2,340 in |
Hydraulic System
| Hydraulic Flow - Standard - Hydraulic Power (Calculated) | 44.0 hp |
|---|---|
| Hydraulic Flow - Standard - Loader Hydraulic Pressure | 3,335 psi |
| Hydraulic Flow - Standard - Loader Hydraulic Flow | 23.0 gal/min |
| Hydraulic Flow - High Flow XPS - Hydraulic Power (Calculated) | 76.0 hp |
| Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Flow | 32.0 gal/min |
| Hydraulic Flow - High Flow XPS - Maximum Loader Hydraulic Pressure | 4,061 psi |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 84 in |
| Length with Bucket on Ground | 146 in |
| Turning Radius from Center - machine rear | 67 in |
| Length - without Bucket | 118 in |
| Bucket Pin Height - Maximum Lift | 126 in |
| Clearance at Maximum Lift and Dump | 98 in |
| Maximum Overall Height | 160 in |
| Bucket Pin Height - Carry Position | 8 in |
| Reach - Maximum Lift/Dump | 24 in |
| Departure Angle | 38 ° |
| Rack Back Angle - Maximum Height | 94 ° |
| Maximum Dump Angle | 39 ° |
| Length - Track on Ground | 71 in |
| Overall Length - Track | 90 in |
| Vehicle Width | 78 in |
| Maximum Reach - With Arms Parallel to Ground | 55 in |
| Turning Radius from Center - Coupler | 59 in |
| Turning Radius from Center - Bucket | 92 in |
Cab & Operator
| ROPS | ISO 3471:2008 |
|---|---|
| FOPS | ISO 3449:2005 Level I |
| FOPS Level II | ISO 3449:2005 Level II |
General Specifications
| Operating Width IN. (CM) | 78 (198) — Starting 2016 Model Year |
|---|---|
| Engine Power HP (KW) | 73 (54) — Starting 2016 Model Year |
| OPERATING LOAD LBS. (KG) | 3,290 (1,492) — Starting 2016 Model Year |
Loader
| Operating Width | 78 in |
|---|---|
| Operating Load Rating | 2,303 lb |
Service Refill Capacities
| Cooling System | 3.7 gal |
|---|---|
| Hydraulic Tank | 10.3 gal |
| Fuel Tank | 24.8 gal |
| Engine Crankcase | 3.0 gal |
| Hydraulic System | 13.7 gal |
Power Train
| Travel Speed - Forward or Reverse - One Speed | 5.2 mph |
|---|---|
| Travel Speed - Forward or Reverse - Two Speed | 8.0 mph |
Air Conditioning System
| Air Conditioning | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.0 kg of refrigerant which has a CO2 equivalent of 1.430 metric tonnes. |
|---|
Noise Level
| Inside Cab* | 81 dB(A) |
|---|---|
| Note (1) | Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe. |
| Note (3) | ***The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC. |
| Outside Cab** | 103 dB(A) |
