Caterpillar
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 79.0 gal |
|---|---|
| Cooling System Fluid Capacity | 9.3 gal |
| Final Drives Fluid Capacity | 1.9 gal |
| Hydraulic Fluid Capacity | 7.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 95 A |
Engine
| Engine Model | C6.6 ACERT |
|---|---|
| Displacement | 403 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 150.0 hp |
| Number of Cylinders | 6 |
| Make | Cat |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 124 in |
| Width Over Tracks | 98 in |
| Length w/o Blade | 148 in |
Transmission
| Max Speed - Forward | 6.3 mph |
|---|---|
| Max Speed - Reverse | 7.3 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 5 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 85 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 46 |
| Standard Shoe Size | 33 in |
| Ground Contact Area | 8,122 in³ |
Standard Blade
| Width | 161 in |
|---|---|
| Capacity | 4.20 yd³ |
