Caterpillar
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Cooling System Fluid Capacity | 19.9 gal |
|---|---|
| Final Drives Fluid Capacity | 3.5 gal |
| Engine Oil Capacity | 7.3 gal |
| Hydraulic Fluid Capacity | 14.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Power Measured @ | 2,100 rpm |
|---|---|
| Net Power | 230.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 46.8 gal/min |
|---|---|
| Relief Valve Pressure | 3,306 psi |
| Pump Type | Piston |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Length of Track on Ground | 114 in |
| Length w/ Blade | 229 in |
Transmission
| Transmission Type | Power Shift |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Track Gauge | 78 in |
|---|---|
| Number of Track Rollers per Side | 7 |
| Number of Shoes per Side | 40 |
| Standard Shoe Size | 22 in |
Standard Blade
| Width | 155 in |
|---|
