Caterpillar

D8R II

Crawler Dozer

Operating Weight
82,960 lb
Max Speed - Forward
6.6 mph
Gross Power
310.0 hp
All crawler dozers
Caterpillar D8R II Crawler Dozer
1 / 5
Image 1 of 5
Image: ironmartonline.com

Specifications

25 data points

Operating Specifications

Operating Specifications specifications
Operating Weight82,960 lb
Fuel Capacity165.2 gal

Engine

Engine specifications
Engine Model3406E TA
Displacement891 in³
Power Measured @2,000 rpm
Gross Power310.0 hp
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance24 in
Height - Top of Cab139 in
Length of Track on Ground127 in
Width Over Tracks107 in
Length w/ Blade259 in
Length w/o Blade194 in

Transmission

Transmission specifications
Max Speed - Forward6.6 mph
Max Speed - Reverse8.6 mph
Number of Forward Gears3
Number of Reverse Gears3

Undercarriage

Undercarriage specifications
Ground Pressure15 psi
Track Gauge83 in
Number of Track Rollers per Side8
Standard Shoe Size22 in
Ground Contact Area5,544 in³

Standard Blade

Standard Blade specifications
Width156 in
Height67 in
Capacity11.41 yd³
