Caterpillar
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Fuel Capacity | 216.0 gal |
|---|---|
| Final Drives Fluid Capacity | 5.0 gal |
| Engine Oil Capacity | 12.0 gal |
| Hydraulic Fluid Capacity | 19.0 gal |
| Operating Voltage | 24 V |
Engine
| Displacement | 1,099 in³ |
|---|---|
| Power Measured @ | 1,900 rpm |
| Number of Cylinders | 8 |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Length of Track on Ground | 137 in |
| Width Over Tracks | 117 in |
Transmission
| Max Speed - Forward | 7.4 mph |
|---|---|
| Max Speed - Reverse | 9.1 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 16 psi |
|---|---|
| Track Gauge | 89 in |
| Number of Track Rollers per Side | 8 |
| Standard Shoe Size | 24 in |
