Caterpillar

D9T

Crawler Dozer

Max Speed - Forward
7.3 mph
Gross Power
464.0 hp
All crawler dozers
Caterpillar D9T Crawler Dozer
1 / 5
Image 1 of 5
Image: eccoequipment.com

Specifications

39 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity235.0 gal
Cooling System Fluid Capacity27.5 gal
Final Drives Fluid Capacity3.9 gal
Engine Oil Capacity10.0 gal
Hydraulic Fluid Capacity23.5 gal
Operating Voltage24 V
Alternator Supplied Amperage95 A

Engine

Engine specifications
Engine ModelC18 ACERT
Displacement1,106 in³
Power Measured @1,800 rpm
Gross Power464.0 hp
MakeCat

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity101.0 gal/min
Relief Valve Pressure5,875 psi
Pump TypePiston

Dimensions

Dimensions specifications
Ground Clearance24 in
Height - Top of Cab150 in
Length of Track on Ground137 in
Width Over Tracks113 in
Length w/ Blade261 in
Length w/o Blade193 in

Transmission

Transmission specifications
Max Speed - Forward7.3 mph
Max Speed - Reverse8.9 mph
Transmission TypePower Shift
Number of Forward Gears3
Number of Reverse Gears3

Undercarriage

Undercarriage specifications
Ground Pressure16 psi
Track Gauge89 in
Number of Track Rollers per Side8
Number of Shoes per Side43
Standard Shoe Size24 in
Ground Contact Area6,569 in³
Track Pitch10 in

General Specifications

General Specifications specifications
Weight lbs (kg)94,265 (42,758) Starting 2019 Model Year
Engine typeCat C18 ACERT Starting 2019 Model Year
Engine Power HP (KW)410 (306) Starting 2019 Model Year

Standard Blade

Standard Blade specifications
Width172 in
Height7 in
Capacity17.70 yd³
