Caterpillar
Liugong
CLG856 II
Wheel Loader
36 specifications
Caterpillar
R1300G
- Operating Weight
- 61,178 lb
- Bucket Capacity - heaped
- 4.09 yd³
- Gross Power
- 165.0 hp
- Net Power
- 140.9 hp
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 61,178 lb |
|---|---|
| Fuel Capacity | 78.0 gal |
| Tire Size | 17.5x25 20 ply |
| Hydraulic System Fluid Capacity | 23.3 gal |
| Static Tipping Weight | 45,360 lb |
| Turning Radius | 227 in |
| Engine Oil Fluid Capacity | 6.7 gal |
| Rear Axle Oscillation | 20 ° |
| Front Axle/Diff Fluid Capacity | 10.1 gal |
| Rear Axle/Diff Fluid Capacity | 11.1 gal |
| Cooling System Fluid Capacity | 17.7 gal |
| Transmission Fluid Capacity | 11.9 gal |
Engine
| Engine Model | 3306B DITA |
|---|---|
| Displacement | 641 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 165.0 hp |
| Net Power | 140.9 hp |
Hydraulic System
| Raise Time | 5.0 s |
|---|---|
| Lower Time | 2.3 s |
| Dump Time | 2.0 s |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 84 in |
| Wheelbase | 121 in |
| Width Over Tires | 76 in |
| Reach at Max Lift and Dump | 62 in |
| Length with Bucket on Ground | 359 in |
| Hinge Pin - Max Height | 115 in |
Transmission
| Max Speed - Forward | 15.0 mph |
|---|---|
| Max Speed - Reverse | 14.3 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.09 yd³ |
|---|---|
| Dump Clearance at Max Raise | 62 in |
| Breakout Force | 26,504 lb |
| Bucket Width | 88 in |
