Challenger
New Holland
TC35
Tractor
21 specifications
Challenger
MT265B
- Operating Weight
- 3,136 lb
- Displacement
- 91 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 33.0 hp
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 3,136 lb |
|---|---|
| Fuel Capacity | 10.6 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,535 lb |
| 3 Point Hitch Type | Cat.1 |
| Turning Radius | 1,322 in |
Engine
| Displacement | 91 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 33.0 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| PTO Power | 26.0 hp |
Hydraulic System
| Pump Flow Capacity | 12.7 gal/min |
|---|---|
| Relief Valve Pressure | 2,276 psi |
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Height - Top of Cab | 88 in |
| Wheelbase | 71 in |
| Overall Length | 10 in |
| Tire Size | (F)8-16 6ply;(R)12.4-24 6ply |
| Width Outside Frame | 62 in |
Transmission
| Max Speed | 18.8 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | Synchroshuttle |
| Number of Reverse Gears | 8 |
