Challenger
New Holland
TC35
Tractor
21 specifications
Challenger
MT285
- Operating Weight
- 3,001 lb
- Displacement
- 91 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 40.1 hp
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 3,001 lb |
|---|---|
| Fuel Capacity | 7.9 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,100 lb |
| 3 Point Hitch Type | Cat I |
Engine
| Displacement | 91 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 40.1 hp |
| Number of Cylinders | 3 |
| Aspiration | Turbocharged |
| PTO Power | 32.4 hp |
Hydraulic System
| Pump Flow Capacity | 12.2 gal/min |
|---|---|
| Relief Valve Pressure | 2,130 psi |
Dimensions
| Height - Top of Cab | 94 in |
|---|---|
| Wheelbase | 70 in |
| Overall Length | 10 in |
| Tire Size | Front 25x8.50 -14 Rear 15 - 19.5 |
| Width Outside Frame | 61 in |
Transmission
| Number of Forward Gears | 16 |
|---|---|
| Transmission Type | Synchronized Power Shuttle |
| Number of Reverse Gears | 16 |
