Challenger
New Holland
TC35
Tractor
21 specifications
Challenger
MT295B
- Operating Weight
- 3,726 lb
- Displacement
- 180 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 52.1 hp
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 3,726 lb |
|---|---|
| Fuel Capacity | 13.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,086 lb |
| 3 Point Hitch Type | Cat.I |
Engine
| Displacement | 180 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 52.1 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| PTO Power | 41.0 hp |
Hydraulic System
| Pump Flow Capacity | 16.2 gal/min |
|---|---|
| Relief Valve Pressure | 2,276 psi |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 91 in |
| Wheelbase | 77 in |
| Overall Length | 11 in |
| Tire Size | (F)9.5-16 6ply;(R)16.9-24 6ply |
| Width Outside Frame | 66 in |
Transmission
| Max Speed | 17.7 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | Synchroshuttle |
| Number of Reverse Gears | 8 |
