Challenger
John Deere
8RT 335
Tractor
17 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 60,001 lb |
|---|---|
| Fuel Capacity | 390.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 19,500 lb |
| 3 Point Hitch Type | III/IVN |
| Alternator Supplied Amperage | 185 A |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 36.0 gal |
| Front Tire Size | 710/70R42 |
| Rear Tire Size | 710/70R42 |
Engine
| Engine Model | C18 ACERT |
|---|---|
| Displacement | 1,105 in³ |
| Gross Power | 525.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | Challenger |
| PTO Power | 425.0 hp |
| Stroke | 7 in |
| Bore | 6 in |
Hydraulic System
| Pump Flow Capacity | 43.5 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Relief Valve Pressure | 2,900 psi |
| Hydraulic System Type | Closed center pressure flow compensated |
Dimensions
| Height - Top of Cab | 151 in |
|---|---|
| Wheelbase | 155 in |
| Overall Length | 298 in |
| Width Outside Frame | 200 in |
| Shipping weight | 39,767 lb |
Transmission
| Number of Forward Gears | 16 |
|---|---|
| Transmission Type | Caterpillar Powershift |
| Number of Reverse Gears | 4 |
