Daedong
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 4,167 lb |
|---|---|
| Fuel Capacity | 10.1 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,732 lb |
| 3 Point Hitch Type | Cat. 2 |
| Turning Radius | 178 in |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 2.4 gal |
| Hydraulic System Fluid Capacity | 2.8 gal |
| Engine Oil Capacity | 1.9 gal |
Engine
| Engine Model | SL3105BT |
|---|---|
| Displacement | 174 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 44.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 36.0 hp |
Hydraulic System
| Pump Flow Capacity | 10.2 gal/min |
|---|---|
| Relief Valve Pressure | 2,321 psi |
Dimensions
| Height - Top of Cab | 70 in |
|---|---|
| Wheelbase | 77 in |
| Overall Length | 12 in |
| Tire Size | front 8.3x20 rear 12.4x28 |
| Width Outside Frame | 84 in |
Transmission
| Max Speed | 19.9 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | gear |
| Number of Reverse Gears | 4 |
Axles
| Final Drive | spiral bevel gear |
|---|
