Daedong
Massey Ferguson
1734
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 650 lb |
|---|---|
| Fuel Capacity | 26.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,291 lb |
| 3 Point Hitch Type | Category II |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 4.9 gal |
| Engine Oil Capacity | 2.8 gal |
Engine
| Engine Model | 1104C-44 |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 72.4 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 12.0 gal/min |
|---|
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 110 in |
| Wheelbase | 91 in |
| Overall Length | 15 in |
| Tire Size | front 11.2-24 rear 18.4-30 |
| Width Outside Frame | 79 in |
Transmission
| Max Speed | 19.9 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | full synchromesh |
| Number of Reverse Gears | 16 |
