Daedong
New Holland
TC35
Tractor
21 specifications
Daedong
EX35 HST
- Operating Weight
- 3,669 lb
- Displacement
- 112 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 38.0 hp
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 3,669 lb |
|---|---|
| Fuel Capacity | 11.9 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,383 lb |
| 3 Point Hitch Type | Cat. I |
| Turning Radius | 113 in |
Engine
| Engine Model | 3B183LXH |
|---|---|
| Displacement | 112 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 38.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 27.0 hp |
Hydraulic System
| Pump Flow Capacity | 15.3 gal/min |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 95 in |
| Wheelbase | 70 in |
| Overall Length | 11 in |
| Tire Size | front 7-16 rear 12.4-24 |
| Width Outside Frame | 61 in |
Transmission
| Max Speed | 17.3 mph |
|---|---|
| Number of Forward Gears | — |
| Transmission Type | hydrostatic |
Comparable machines
Other tractors in a similar weight class.
