Daedong
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 3,594 lb |
|---|---|
| Fuel Capacity | 7.4 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,520 lb |
| 3 Point Hitch Type | Cat. I |
| Turning Radius | 114 in |
Engine
| Engine Model | 4A220A |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 46.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 11.9 gal/min |
|---|
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 90 in |
| Wheelbase | 71 in |
| Overall Length | 11 in |
| Tire Size | front 9.5-16 rear 13.6-26 |
| Width Outside Frame | 59 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Transmission Type | constant |
| Number of Reverse Gears | 8 |
