Doosan
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 132.1 gal |
|---|---|
| Hydraulic System Fluid Capacity | 81.9 gal |
| Cooling System Fluid Capacity | 14.3 gal |
| Engine Oil Capacity | 9.6 gal |
| Swing Drive Fluid Capacity | 1.9 gal |
| DEF tank capacity | 18.5 gal |
Engine
| Engine Model | DC09 |
|---|---|
| Displacement | 568 in³ |
| Number of Cylinders | 5 |
| Bore | 5 in |
| Stroke | 6 in |
| Alternator | 100 A |
| Air cleaner | Double Elements |
| Battery | 200 AH |
| Net Torque | 940 lb-ft |
| Starter | 8.1 hp |
| Gross horsepower | 270.9 hp |
Hydraulic System
| Pump Flow Capacity | 131.0 gal/min |
|---|---|
| Relief Valve Pressure | 4,694 psi |
Dimensions
| Ground Clearance | 32 in |
|---|---|
| Height - Top of Cab | 183 in |
| Overall Width | 143 in |
| Length of Track on Ground | 569 in |
| Tail Swing Radius | 128 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Counterweight, Standard | 13,889 lb |
| Rollers And Idlers | 2 |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 87,786 lb-ft |
Boom/Stick Log Loader Option 1
| Max Height | 517 in |
|---|---|
| Max Reach at Ground Level | 446,064 in |
| Shipping Height | 142 in |
| Boom/Stick Option (LGL) 1 | Boom - 20 ft 8 in /Arm - 12 ft 10 in |
| Shipping Length | 569 in |
| Max Depth Below Ground | 148 in |
