Dressta
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Fuel Capacity | 45.0 gal |
|---|---|
| Cooling System Fluid Capacity | 4.9 gal |
| Engine Oil Capacity | 3.0 gal |
| Hydraulic Fluid Capacity | 18.5 gal |
| Operating Voltage | 12 V |
Engine
| Engine Model | QSB4.5 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 110.0 hp |
| Net Power | 101.0 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 306 lb-ft |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 108 in |
| Length of Track on Ground | 86 in |
| Width Over Tracks | 86 in |
| Length w/ Blade | 176 in |
Transmission
| Max Speed - Forward | 6.2 mph |
|---|---|
| Max Speed - Reverse | 7.4 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 67 in |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 39 |
| Standard Shoe Size | 20 in |
| Ground Contact Area | 3,440 in³ |
| Track Pitch | 7 in |
General Specifications
| Weight lbs (kg) | 20,348 (9,230) — Starting 2019 Model Year |
|---|---|
| Engine type | Cummins QSB 4.5 — Starting 2019 Model Year |
| Engine Power HP (KW) | 101 (75) — Starting 2019 Model Year |
