Dynapac
Hamm
GRW 180i-12H
Pneumatic Roller
26 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Max Speed | 15.0 mph |
|---|---|
| Fuel Capacity | 26.5 gal |
| Water Spray Tank Fluid Capacity | 1,188.7 gal |
Engine
| Engine Model | HIN0 W06D |
|---|---|
| Displacement | 352 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 96.0 hp |
| Aspiration | natural |
Weights
| Operating Weight - standard | 18,409 lb |
|---|---|
| Operating Weight - max ballast | 33,069 lb |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 146 in |
| Overall Length | 16 in |
| Overall Width | 81 in |
| Height - Top of ROPS/FOPS | 101 in |
Tires & Wheels
| Number of Tires - Rear | 5 |
|---|---|
| Number of Tires - Front | 4 |
| Wheel Track/Tire Overlap | 1 in |
| Standard Tire Size | 9.00-20-10 ply |
