Dynapac

CT260

Rammer

Operating Weight
47,179 lb
Max Speed
14.0 mph
Height - Top of Cab
139 in
Width Over Wheels
33 in
All rammers
Dynapac CT260 Rammer
1 / 5
Image 1 of 5
Image: dynapacparts.com

Specifications

24 data points

Operating Specifications

Operating Specifications specifications
Operating Weight47,179 lb
Fuel Capacity105.7 gal
Operating Voltage12 V
Operating Width141 in

Engine

Engine specifications
Engine Model6CT8.3
Power Measured @2,200 rpm
Net Power210.0 hp
Aspirationnatural
MakeCummins

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab139 in
Wheelbase128 in
Turning Radius - Inside107 in
Width Over Wheels33 in

Transmission

Transmission specifications
Max Speed14.0 mph
Number of Forward Gears4
Number of Reverse Gears4
Transmission Typetwin disc

Drum

Drum specifications
Drum Width39 in

Blades

Blades specifications
Blade Width33 in

Wheels

Wheels specifications
Front Wheels Drum Diameter0 in
Front Wheels Drum Width0 in
Rear Wheels Drum Diameter0 in
Rear Wheels Drum Width0 in
