Fendt

209 FA

Tractor

Operating Weight
5,908 lb
Displacement
263 in³
Power Measured @
2,300 rpm
Gross Power
92.6 hp
All tractors
Fendt 209 FA Tractor
1 / 5
Image 1 of 5
Image: allmachines.com

Specifications

19 data points

Operating Specifications

Operating Specifications specifications
Operating Weight5,908 lb
Fuel Capacity18.5 gal
Alternator Supplied Amperage55 A

Engine

Engine specifications
Displacement263 in³
Power Measured @2,300 rpm
Gross Power92.6 hp
Net Power88.6 hp
Number of Cylinders4
Torque Rise24.0 %

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity19.6 gal/min
Relief Valve Pressure2,901 psi

Dimensions

Dimensions specifications
Height - Top of Cab96 in
Wheelbase86 in
Overall Length12 in
Width Outside Frame55 in

Transmission

Transmission specifications
Max Speed24.9 mph
Number of Forward Gears20
Transmission TypeOverdrive fully synchronmesh close-ratio
Number of Reverse Gears6
