Ford
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 6,799 lb |
|---|---|
| Fuel Capacity | 21.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 4,136 lb |
| Alternator Supplied Amperage | 32 A |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 15.0 gal |
Engine
| Displacement | 269 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 82.0 hp |
| Net Power | 78.5 hp |
| Number of Cylinders | 4 |
| Max Torque | 219 lb-ft |
| Engine Make | Ford |
| PTO Power | 72.0 hp |
| Stroke | 5 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 9.7 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
| Hydraulic System Type | Open center |
| Maximum system pressure | 2,500 psi |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 88 in |
| Overall Length | 145 in |
| Overall Width | 70 in |
| Height - Top of ROPS/FOPS | 96 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Number of Reverse Gears | 2 |
Production
| Series | 10 Series |
|---|---|
| Year Manufactured | 1,982 – 1,993 |
Comparable machines
Other tractors in a similar weight class.
