Gleaner
Fendt
6250 E
Combine
11 specifications
Gleaner
A85
- Operating Weight w/o Attachment
- 37,700 lb
- Fuel Capacity
- 229.9 gal
- Displacement
- 763 in³
- Power
- 425.0 hp
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight w/o Attachment | 37,700 lb |
|---|---|
| Fuel Capacity | 229.9 gal |
| Transmission Type | 4 speed hydrostatic |
Engine
| Engine Model | C13 ACERT |
|---|---|
| Displacement | 763 in³ |
| Power Measured @ | 2,100 rpm |
| Power | 425.0 hp |
Dimensions
| Wheelbase | 146 in |
|---|---|
| Overall Length | 393 in |
| Height to Top of Isomount Cab | 148 in |
Cleaning System
| Total Cleaning Area | 8,293 in³ |
|---|---|
| Cleaning Fan Speed - High | 1,350 rpm |
| Cleaning Fan Speed - Low | 500 rpm |
Feeding
| Conveyor Width | 56 in |
|---|
Grain Handling
| Grain Tank Capacity | 3,258.2 gal |
|---|---|
| Unloading Speed | 4.6 bu/sec |
| Unloading Discharge Height | 172 in |
| Unloading Auger Length | 292 in |
Separating
| Separating Area | 2,387 in³ |
|---|---|
| Separator Type | rotary |
Threshing
| Rotor Diameter | 32 in |
|---|---|
| Rotor Length | 140 in |
| Rotor Speed - High | 1,040 rpm |
| Rotor Speed - Low | 200 rpm |
| Concave Area | 2,713 in³ |
