Goldoni
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 3,649 lb |
|---|---|
| Fuel Capacity | 10.6 gal |
| 3 Point Hitch Type | Class I |
| Turning Radius | 110 in |
Engine
| Displacement | 101 in³ |
|---|---|
| Power Measured @ | 2,800 rpm |
| Net Power | 32.2 hp |
| Number of Cylinders | 3 |
| Torque Rise | 20.0 % |
Hydraulic System
| Pump Flow Capacity | 8.8 gal/min |
|---|
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 86 in |
| Wheelbase | 65 in |
| Overall Length | 10 in |
| Tire Size | front 200/70x16 Rear320/70x24 |
| Width Outside Frame | 60 in |
Transmission
| Max Speed | 18.7 mph |
|---|---|
| Number of Forward Gears | 12 |
| Number of Reverse Gears | 12 |
