Goldoni
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 4,189 lb |
|---|---|
| Fuel Capacity | 13.3 gal |
| 3 Point Hitch Type | Class 1 and 2 |
| Turning Radius | 131 in |
Engine
| Displacement | 181 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Net Power | 67.1 hp |
| Number of Cylinders | 4 |
| Torque Rise | 15.0 % |
Hydraulic System
| Pump Flow Capacity | 10.1 gal/min |
|---|
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 86 in |
| Wheelbase | 73 in |
| Overall Length | 11 in |
| Tire Size | Front 8.25x16\" |
| Width Outside Frame | 72 in |
Transmission
| Max Speed | 18.7 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | 40 speeds a lever can be used to select the 8+8 transmission with synchronized reverse shuttle or the 16+8 transmission with synchronized Dual power |
| Number of Reverse Gears | 8 |
