Grove

GMK5180

All Terrain Crane

Gross Power
563.3 hp
Transport Width
119 in
All all terrain cranes
Grove GMK5180 All Terrain Crane
1 / 5
Image 1 of 5
Image: wppecrane.com

Specifications

32 data points

Operating Specifications

Operating Specifications specifications
Tire Size14.00 R25
Carrier Fuel Capacity105.7 gal
Operating Voltage24 V
Number of Axels5
Alternator Supplied Amperage100 A
Upper Structure Fuel Capacity52.9 gal

Dimensions

Dimensions specifications
Transport Width119 in
Transport Height156 in
Transport Length609 in
Width w/ Outriggers Extended328 in
Upper Structure Tail Swing Radius197 in
Carrier Length521 in

Transmission

Transmission specifications
Transmission TypeAllison automatic CLT 755
Number of Forward Gears5
Number of Reverse Gears1

Boom

Boom specifications
Number of Sections6
Max Height @ Max Raise Angle - no jib2,363 in
Min Height @ Max Raise Angle531 in
Max Elevating Angle82 °

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power563.3 hp
Max Torque1,991 lb-ft
Torque Measured @1,080 rpm
MakeGrove
Power Measured @1,800 rpm
Number of cylinders8
AspirationTurbocharged
Emission LevelEURO II / EUROMOT / EPA / CARB

UPPER STRUCTURE ENGINE

UPPER STRUCTURE ENGINE specifications
Gross Power163.7 hp
MakeGrove
Max Torque487 lb-ft
Torque Measured @1,200 rpm
Power Measured @2,100 rpm
