Grove
XCMG
QY70K
Truck Crane
Specifications pending
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Operating Voltage | 24 V |
|---|---|
| Upper Structure Hydraulic System Fluid Capacity | 305.0 gal |
| Upper Structure Fuel Capacity | 78.0 gal |
Dimensions
| Width w/ Outriggers Extended | 276 in |
|---|---|
| Upper Structure Tail Swing Radius | 168 in |
Transmission
| Number of Forward Gears | 5 |
|---|---|
| Number of Reverse Gears | 1 |
Boom
| Max Lift Capacity | 159,835 lb |
|---|---|
| Max Elevating Angle | 80 ° |
| Number of Sections | 4 |
CARRIER ENGINE
| Make | Grove |
|---|
UPPER STRUCTURE ENGINE
| Net Power | 178.0 hp |
|---|---|
| Displacement | 318 in³ |
| Make | Grove |
| Power Measured @ | 2,500 rpm |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 410 lb-ft |
