Grove
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Voltage | 24 V |
|---|---|
| Carrier Fuel Capacity | 60.0 gal |
| Upper Structure Hydraulic System Fluid Capacity | 111.0 gal |
| Turning Radius | 133 in |
Weights
| Counterweight | 2,000 lb |
|---|
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Transport Height | 131 in |
| Transport Length | 521 in |
| Width w/ Outriggers Extended | 240 in |
| Upper Structure Tail Swing Radius | 133 in |
| Carrier Length | 451 in |
Transmission
| Number of Forward Gears | 6 |
|---|---|
| Number of Reverse Gears | 1 |
| Transmission Type | Allison Automatic |
Boom
| Max Lift Capacity | 80,000 lb |
|---|---|
| Max Elevating Angle | 80 ° |
| Number of Sections | 3 |
| Swing Speed | 3 rpm |
| Min Working Radius | 120 in |
| Max Working Radius | 960 in |
CARRIER ENGINE
| Power Measured @ | 2,200 rpm |
|---|---|
| Make | Grove |
| Torque Measured @ | 1,400 rpm |
| Number of cylinders | 6 |
