Hesston

7430

Baler

Bale Width
32 in
Overall Width
108 in
Overall Width
101 in
Overall Height
125 in
All balers
Hesston 7430 Baler
1 / 5
Image 1 of 5
Image: cloudstore.co

Specifications

21 data points

Dimensions

Dimensions specifications
Overall Length390 in
Overall Width101 in
Overall Height125 in
Weight17,840 lb
Tractor PTO Power Required100.0 hp

Bale Size

Bale Size specifications
Bale Width32 in
Bale Length - max100 in
Bale Height35 in
Bale Weight - max1,500 lb
Bale Weight - min1,000 lb

Baler Pickup

Baler Pickup specifications
Overall Width108 in
Tine to Tine Width71 in
Number of Tines112
Lift TypeHydraulic cylinder

Feeding Chamber

Feeding Chamber specifications
Packer TypeFork type w/ 4 Hard Surfaced Tines
Stuffer TypeFork type

Plunger

Plunger specifications
SPM41
Stroke Length28 in
Bearing Type4 Tapered Roller Bearings (Sealed)

Wrapping System

Wrapping System specifications
Twine Ball Capacity20
Twine TypeFour Double Knot Type
