Hesston

9230

Mower Conditioner

Operating Weight w/o Attachment
8,500 lb
Max Speed
11.0 mph
Displacement
201 in³
Power
85.0 hp
All mower conditioners/windrowers
Hesston 9230 Mower Conditioner
1 / 5
Image 1 of 5
Image: tractorhouse.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight w/o Attachment8,500 lb
Fuel Capacity60.0 gal
Front Tire Size16.9 x 28 Bar Tread
Rear Tire Size14L - 16.1
Alternator Supplied Amperage60 A
Operating Voltage12 V
Hydraulic System Fluid Capacity23.0 gal
Engine Oil Capacity2.8 gal

Engine

Engine specifications
Displacement201 in³
Power85.0 hp
AspirationTurbocharged
Power Measured @2,600 rpm
Engine ModelDiesel B3.3T

Dimensions

Dimensions specifications
Ground Clearance40 in
Height - Top of Cab133 in
Wheelbase141 in
Overall Width148 in
Front Wheel Tread Width128 in
Rear Wheel tread Width - max120 in
Rear Wheel Tread Width - min85 in
Length w/ Header258 in

Transmission

Transmission specifications
Max Speed11.0 mph
Final Drive TypePlanetary
