Hesston

9240

Mower Conditioner

Operating Weight w/o Attachment
8,650 lb
Max Speed
15.0 mph
Displacement
274 in³
Power
110.0 hp
All mower conditioners/windrowers
Hesston 9240 Mower Conditioner
1 / 5
Image 1 of 5
Image: jandcauctiononline.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight w/o Attachment8,650 lb
Fuel Capacity60.0 gal
Front Tire Size18.4 x 26 Turf Tread
Rear Tire Size14L - 16.1
Alternator Supplied Amperage95 A
Operating Voltage24 V
Hydraulic System Fluid Capacity23.0 gal
Engine Oil Capacity2.1 gal

Engine

Engine specifications
Displacement274 in³
Power110.0 hp
AspirationTurbocharged
Power Measured @2,500 rpm
Engine ModelDiesel 4.5QSBTII

Dimensions

Dimensions specifications
Ground Clearance40 in
Height - Top of Cab133 in
Wheelbase141 in
Overall Width148 in
Front Wheel Tread Width126 in
Rear Wheel tread Width - max120 in
Rear Wheel Tread Width - min85 in
Length w/ Header258 in

Transmission

Transmission specifications
Max Speed15.0 mph
Final Drive TypePlanetary
