Hesston

9260

Mower Conditioner

Operating Weight w/o Attachment
9,430 lb
Max Speed
16.0 mph
Displacement
359 in³
Power
185.0 hp
All mower conditioners/windrowers
Hesston 9260 Mower Conditioner
1 / 5
Image 1 of 5
Image: auctiontime.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight w/o Attachment9,430 lb
Fuel Capacity80.0 gal
Front Tire Size23.1 x 26 Turf Tread
Rear Tire Size14L - 16.1
Alternator Supplied Amperage95 A
Operating Voltage24 V
Hydraulic System Fluid Capacity22.0 gal
Engine Oil Capacity4.0 gal

Engine

Engine specifications
Displacement359 in³
Power185.0 hp
AspirationTurbocharged
Power Measured @2,500 rpm
Engine ModelDiesel 5.9QSB-185A

Dimensions

Dimensions specifications
Ground Clearance41 in
Height - Top of Cab134 in
Wheelbase141 in
Overall Width156 in
Front Wheel Tread Width132 in
Rear Wheel tread Width - max120 in
Rear Wheel Tread Width - min85 in
Length w/ Header257 in

Transmission

Transmission specifications
Max Speed16.0 mph
Final Drive TypeDouble Planetary Gear Reduction
