Stavostroj
VV1400D
Walk-Behind Compactor
21 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 27,975 lb |
|---|---|
| Max Speed | 7.5 mph |
| Fuel Capacity | 66.1 gal |
| Operating Voltage | 12 V |
Engine
| Engine Model | QSB4.5 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 160.0 hp |
| Number of Cylinders | 4 |
| Make | Cummins |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 10 in |
| Overall Width | 32 in |
| Turning Radius - Inside | 143 in |
| Overall Length w/o Blade | 230 in |
Tires & Wheels
| Tires | 23.1-26/12PR |
|---|
Drum
| Drum Width | 84 in |
|---|---|
| Drum Diameter | 58 in |
| Centrifugal Force - High | 44,512 lb |
| Nominal Amplitude - High | 0 in |
| Vibration Frequency 1 | 30 vpm |
| Vibratory Frequency 2 | 36 vpm |
| Number of Pads | 150 |
| Frequency | 1,800 – 2,160 vpm |
| Pad Surface Area | 21 in³ |
| Pad Height | 4 in |
