Hyundai
Cukurova
CF25FX
Forklift
Specifications pending
.jpg)
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Number of Front Wheels | 2 |
|---|---|
| Number of Rear Wheels | 2 |
Engine
| Engine Model | 4TNE98 |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,300 rpm |
| Power | 62.0 hp |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 66 in |
| Overall Width | 60 in |
| Turning Radius | 93 in |
| Overall Height - mast lowered | 86 in |
| Length to Fork Face | 103 in |
| Height to Top of Overhead Guard | 86 in |
| Max Fork Height | 131 in |
Mast
| Load Capacity | 5,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 4.8 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 10 ° |
| Lower Speed | 3.7 mph |
