Hyundai
Cukurova
CF25FX
Forklift
Specifications pending
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Max Speed | 20.6 mph |
|---|---|
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
Engine
| Engine Model | S6S-DT |
|---|---|
| Displacement | 305 in³ |
| Power Measured @ | 2,200 rpm |
| Power | 88.0 hp |
| Torque | 252 lb-ft |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 91 in |
| Overall Width | 83 in |
| Turning Radius | 130 in |
| Overall Height - mast lowered | 100 in |
| Length to Fork Face | 138 in |
| Height to Top of Overhead Guard | 100 in |
| Max Fork Height | 119 in |
Mast
| Load Capacity | 11,023 lb |
|---|---|
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 15 ° |
| Mast Tip Rear | 10 ° |
| Lower Speed | 1.1 mph |
